SPECIFICATIONS FT 60
Performance Data
Maximum Torque
20.6 Kgm at 1200 rpm
Engine
Type
4 Stroke, Direct Injection (DI), Water-Cooled, Diesel engine
No. of Cylinders
3
Bore x stroke (mm)
111.76 x 106.68
Displacement (cc)
3147
Air Cleaner
Oil Bath, Centrifugal type pre-air cleaner
Transmission
Clutch Type
280 mm dia, dry single plate (Dual Clutch Optional)
Type of Gear Box
Mechanical, constant mesh gears
No. of speeds
8 Forward and 2 Reverse
Road Speeds (Km/Hr)
At 2000 engine rpm
(with rear tyre size – 13.6 x 28)
Forward
1st
2.76
2nd
3.45
3rd
6.04
4th
8.25
5th
9.87
6th
12.34
7th
21.68
8th
29.48
Reverse
Low – 3.96
High – 14.24
Differential Lock
Foot operated, dog clutch, automatic disengagement
Power Take Off
Type
Transmission PTO
No. & Size Splines
6 splines, 36 m dia
PTO Speed
540 rpm at 1600 engine rpm
Hydraulics
Type
Fully independent, 2 lever, ADDC
Double acting top link sensing and
Blending of depth and draft control
Linkage
3 point linkage, category II
Lifting Capacity (Kg)
1050 at ends of the lower link
Steering
Type
Re-circulating ball type, worm & nut with double drop arms
(Power steering optional)
Tyres
Size of Front Tyres
6.00 x 16 –8 PR
Size of Rear Tyres
13.6 x 28 –8 PR
Brakes
Type
Dry Disc Brakes
Parking Brake
Hand operated
Capacities (Litres)
Diesel tank
49.2
Engine
6.5
Cooling System
13.5
Gear Box
11.5
Rear Axle
23.3
Adjustable Wheel Track
Front (mm)
1220 –1930 (8 Positions)
Rear (mm)
1347 – 1957 (7 Positions)
Weight of Tractor (Kg)
1985
Weight of Front Axle (Kg)
785
Weight of Rear Axle (Kg)
1200
|
